Forma Makina


Machine Details


Forma Makina
WIDTH
3350 mm


Forma Makina
LENGTH
25610 mm


Forma Makina
HEIGHT
3750 mm


Forma Makina
WEIGHT
55000 kg


Forma Makina
CONSUMPTION (kWh)
39 kW



Products / Wafer Production Lines / WAFER BAKING OVENS


WAFER BAKING OVENS


A UNIQUE SOLUTION COMBINING MODULAR DESIGN WITH HIGH QUALITY!

Wafer baking machines ensure flat or hollow wafer sheets are produced in a fully automated manner.Depending on requests of customers, baking plates are designed to produce wafers with thin, medium or deep reeding.Designed in accordance with Industry 4.0, our baking ovens enable to control data in terms of capacity, energy, efficiency, maintenance, etc. at a single point.

  • Maximum capacity of 55 sheets/minute (350 kg/h)
  • Materials suitable for food contact
  • Baking time of 2.1 minutes on average
  • Baking molds with Natural Gas / LPG – Electric operated options (according to requests)
  • Use of gas system and equipment ensuring energy efficiency and operation safety in the oven
  • Even heat distribution over the whole baking surface thanks to burners that can rotate around their own axis
  • Automated and monitor-controlled ignition system for heating of the oven
  • 120 molds in maximum

STANDARD WAFER SHEET SIZES

  • 290 mm * 470 mm (for ovens with profile body)
  • 350 mm * 470 mm (for ovens with cast body)
  • 350 mm * 500 mm (for ovens with cast body)
  • 350 mm * 700 mm (for ovens with cast body)

OPTIONS

Debris conveyor: Enables to discharge bead discards that come out of the oven automatically. It is included in high-capacity ovens as a standard.

Gas meter: Monitors energy consumption of the even in both automatic and manual manner. Complies with Industry 4.0 requirements. It is included in high-capacity ovens as a standard.

Special unlubricated bearing: Baking tong wheels are maintenance-free thanks to specially-designed unlubricated bearings. Both lubrication and maintenance costs are saved.
